定制服务：可按客户要求的光电参数，规格尺寸或特殊要求定做
产品应用：
LED显示屏
LED 背光源
高端数码产
汽车电子
电源指示灯
消费电子类
LED灯条及数码管等
Electro optical characteristics(Ta=25°C)
| Electro optical characteristics(Ta=25°C) | ||||||||||
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 2018 | MH-2018QRQGQBC | Red | 1.8 | 2.4 | 80 | 120 | 620 | 630 | 20 | 120 |
| Pure Green | 2.8 | 3.4 | 300 | 500 | 520 | 530 | ||||
| Blue | 2.8 | 3.4 | 60 | 120 | 460 | 470 | ||||
| 2018 | MH-2018QRQYQBC | Red | 1.8 | 2.4 | 80 | 120 | 620 | 630 | 20 | 120 |
| Yellow | 1.8 | 2.4 | 80 | 120 | 580 | 590 | ||||
| Blue | 2.8 | 3.4 | 60 | 120 | 460 | 470 | ||||
| 2018 | MH-2018QOQWQGC | Red | 1.8 | 2.4 | 80 | 120 | 620 | 630 | 20 | 120 |
| white | 2.8 | 3.4 | 300 | 800 | 5000 | 8000 | ||||
| Pure Green | 2.8 | 3.4 | 300 | 500 | 520 | 530 | ||||
| 2018 | MH-2018QRQYQGC | Red | 1.8 | 2.4 | 80 | 120 | 620 | 630 | 20 | 120 |
| Yellow | 1.8 | 2.4 | 80 | 120 | 580 | 590 | ||||
| Pure Green | 2.8 | 3.4 | 300 | 500 | 520 | 530 | ||||
