定制服务：可按客户要求的光电参数，规格尺寸或特殊要求定做
产品应用：
LED显示屏
LED 背光源
高端数码产
汽车电子
电源指示灯
消费电子类
LED灯条及数码管等
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3216 | MH-3216QRQYC-035 | Red | 1.8 | 2.4 | 80 | 180 | 620 | 630 | 20 | 120 |
| Yellow | 1.8 | 2.4 | 80 | 180 | 585 | 595 | 20 | 120 | ||
| 3216 | MH-3216QRQYGC-035 | Red | 1.8 | 2.4 | 80 | 180 | 620 | 630 | 20 | 120 |
| Yellow-green | 1.8 | 2.4 | 20 | 80 | 560 | 570 | 20 | 120 | ||
| 3216 | MH-3216QRQBC-035 | Red | 1.8 | 2.4 | 80 | 180 | 620 | 630 | 20 | 120 |
| Blue | 2.8 | 3.4 | 80 | 150 | 460 | 470 | 20 | 120 | ||
| 3216 | MH-3216QRQGC-035 | Red | 2.8 | 3.4 | 80 | 180 | 620 | 630 | 20 | 120 |
| Pure Green | 1.8 | 2.4 | 320 | 800 | 520 | 530 | 20 | 120 | ||
| 3216 | MH-3216QRQWC-035 | Red | 1.8 | 2.4 | 80 | 180 | 620 | 630 | 20 | 120 |
| white | 2.8 | 3.4 | 600 | 800 | 2000 | 3000 | 20 | 120 | ||
| 3216 | MH-3216QBQGC-035 | Blue | 2.8 | 3.4 | 80 | 150 | 460 | 470 | 20 | 120 |
| Pure Green | 1.8 | 2.4 | 320 | 800 | 520 | 530 | 20 | 120 | ||
